Structural Glazing Spacer Daim kab xev

Hollyseal® PVC ua npuas ncauj glazing daim kab xev coated ob sab nrog acrylic nplaum. Nws yog tsim los siv nyob rau hauv cov txheej txheem spacer systems thiab muaj ib tug kaw cell qauv tso cai rau kev kho ntawm cov qauv silicones ntawm tag nrho cov sab.
Hollyseal® PVC ua npuas ncauj glazing daim kab xev feem ntau yog siv rau hauv cov ntaub thaiv phab ntsa thiab glazing thiab yog ib qho kev lag luam zoo heev rau kev siv nyiaj ntau ntawm cov urethanes.
Qhov ceev: 300-450kg / m3; Tsis tu ncua Thickness (mm): 1.6,2,3.2,4.8,6.4,8,9.5,12.7
Foam tapes tuaj yeem muab rau hauv koj tus kheej hom.

Khoom piav qhia:

Structureal Glazing Spacer Daim kab xev muaj cov khoom tsis muaj kev laus, zoo tiv thaiv cov kua qaub thiab cov kuab tshuaj thiab tsim nyog rau ntau daim ntawv thov, xws li plua plav sealing, dej sealing, cushioning, poob siab absorbing, thiab lwm yam.

Structural Glazing Spacer Daim kab xev ua raws li ntau qhov chaw, nrog rau cov hlau, yas thiab ntoo. Thaum tshav kub kub resistant PVC ua npuas ncauj daim kab xev yog tsim los siv rau hauv daim ntawv thov sab hauv los yog qhov twg daim ntawv cog lus tsis raug UV hluav taws xob hnyav. Cov kab xev muaj cov khoom zoo heev uas tsis muaj kev laus, ua haujlwm zoo rau cov kua qaub thiab cov kuab tshuaj.

7f8e54edbdd5a2addac3498954ee447_

Khoom qauv:

● Tso tawm liner▕ Polypropylene liner

● Adhesive▕ Acrylic nplaum

● Ua npuas ncauj▕ PVC, dub

8bdd02a59940593e0d51ba604c92c01

Nta:

● Tshem tawm cua, plua plav thiab ya raws

● Thicknesses ntawm 0.5mm txog 16mm

● Zoo tiv thaiv cov kua qaub thiab cov kuab tshuaj

● Cov qauv muaj zog sab hauv tiv thaiv kev tsim kua muag

● Zoo tev lub zog thiab pib adhesion

● High shear, siab tev, siab nplaum loj

● Tau tshaj cov glazing feem ntau

● Zoo vibration dampening thiab cushioning

● Structural Glazing Spacer Daim kab xev nrog lub ntsej muag du

initpintu_

Technical Information:

Qhov ntom	300-450 kg/m³
Ntug 00 Hardness	55-90 degree
Tensile zog	Ntau dua lossis sib npaug li 800kPa
Elongation	Ntau dua lossis sib npaug li 70 feem pua
180 degree Peel Strength	0.82N/mm
30 feem pua Compression set	Tsawg dua lossis sib npaug li 7 feem pua
Flammability	UL94 HBF/HF-1/V-0 TIAB SA 302 (Muaj nyob rau hauv customized)

Daim ntawv thov:

● Qhov zoo tshaj plaws yog siv rau ntawm UPVC, txhuas thiab ntoo qhov rais nruab nrab ntawm iav thiab ncej los yog beading nyob rau hauv ob qho tib si sab hauv thiab sab nraud seals.

● Siv los kaw cov vaj huam sib luag rau lub moj khaum ntawm cov cuab yeej siv huab cua kom tiv thaiv kev khiav tawm ntawm huab cua thiab kev co hauv cov chav nyob.
